Description
Reproduction for:
BLASI Floor guide left side steel 35mm Art. No.: 10074
If the centre distance from wall to centre of the moveable leaf groove is 35mm, this is the matching floor guide. Because the centre distance of the outer surface from the fastening side up to the centre from the guiding area from the floor guide does also amount to 35mm.
The floor guide shows the following geometries:
Width: 37,5 mm
Height: 37 mm
Length: 100 mm
2 x 5,5 mm slot hole
2 x Ø 6,5 mm bore hole
