BESAM UniSlide pin floor guide 45mm Art. No.: 10005
If the centre distance from wall to centre of the moveable leaf groove is 45mm, this is the matching floor guide. Because the centre distance of the outer surface from the fastening side up to the pin centre of the floor guide does also amount to 45mm.
The floor guide shows the following geometries:
Width: 30 mm
Height: 35 mm
Length: 60 mm
2 x Ø 6 mm bore hole countersunk
2 x 7 mm slot hole
1 x bolt Ø 8mm with a height of 19 mm
