BESAM pin floor guide left side 30mm Art. No.: 10003
bolt for BESAM pin floor guide Art. No.: 10003-1
In case of this version (Art. No.: 10003-1) is supplied as shown in the picture, only the bolt for the BESAM pin floor guide.
If the centre distance from wall to centre of the moveable leaf groove is 30mm, this is the matching floor guide. Because the centre distance of the outer surface from the fastening side up to the pin centre of the floor guide does also amount to 30mm.
The floor guide shows the following geometries:
Width: 40 mm
Height: 30 mm
Length: 87 mm
3 x Ø 7mm bore hole
1 x bolt Ø 5 mm with a height of 15 mm
